ANALOG CODES
CS1000 Code Scanner
OB15-11
69
!&# / "
!&# / "
!&# / "
!&# / "
Models
Model Years
129.061 129.066 129.067 129.076
1990-12/93
Connect wires of Scanner as follows (Model 129.061/066)
Scanner
Data Link Connector 16-pin
Yellow
Socket 10
Black
Socket 1
Red
Socket 160
Connect wires of Scanner as follows (Model 129.067/076, all 129 from 1993)
Scanner
Data Link Connector 38-pin
Yellow
Socket 21
Black
Socket 1
Red
Socket 3
FAULT CODE TABLE
DTC Readout
Possible Cause of Failure
1
No faults stored
2
Limit switch, left locked, soft top storage compartment cover
3
Limit switch, right locked, soft top storage compartment cover
4
Limit switch, left closed, soft top storage compartment cover
5
Limit switch, right closed, soft top storage compartment cover
6
Limit switch, left locked, soft top fabric bow
7
Limit switch, right locked, soft top fabric bow
8
Limit switch, left closed, soft top fabric bow
9
Limit switch, right closed, soft top fabric bow
10
Limit switch, left front locked, soft top
11
Limit switch, right front locked, soft top
12
Limit switch soft top storage compartment cover open
13
Limit switch soft top fabric bow raised
14
Limit switch soft top down (in storage compartment)
15
Limit switch soft top up (secondary closing speed )
