ANALOG CODES
CS1000 Code Scanner OB15-11
72
/#!#& # /# #! .'
/#!#& # /# #! .'
/#!#& # /# #! .'
/#!#& # /# #! .'
Models Model Years
129.061 129.066 129.067 129.076 1990-1993
Connect wires of Scanner as follows
Scanner Data Link Connector 16-pin
Yellow Socket 12
Black Socket 1
Red Socket 16
Scanner Data Link Connector 38-pin
Yellow Socket 31
Black Socket 1
Red Socket 3
FAULT CODE TABLE
DTC Readout Possible Cause of Failure
1 No fault found
2 Infrared remote control module
3 Supply pump, central locking system short to ground
4 Infrared remote control receiver, Left front door/Right front door/Trunk lid Red indicator
lamps, short to ground
5 Infrared remote control receiver, Left front door/Right front door/Trunk lid Green
indicator lamps, short to ground
6 Supply pump, central locking system, short to circuit 30
7 Infrared remote control receiver, Left front door/Right front door/Trunk lid Red indicator
lamps, short to circuit 30 or open circuit
8 Infrared remote control receiver, Left front door/Right front door/Trunk lid Green
indicator lamps, in receiver have short to short to circuit 30 or open circuit
9 Driver door switch group wiring, short to circuit 30 ATA/convenience microswitch wiring
short to circuit 30 ATA/convenience microswitch wiring short to circuit 30
10 Ignition/starter switch-position recognition switch, open circuit
11 Ignition/starter switch-position recognition switch, open circuit 31
12 Left front door actuator, open circuit
13 Right door actuator, open circuit
14 Trunk lid lock actuator, open circuit
