Easiprox split stand alone reader, Statement, System features

background image

Unit: mm

Statement

Dimension

System Features

2 , 0 0 0 c a r d s h o l d e r r e g i s t r a t i o n
provides a powerful extended range
for common community application.

Split off unit for controller board and
reader in ranging up to 50 M bring out
the friendly system device for low
cost but high security with anti-
tampering as well as convenience
and reliability.

Field proven unique Master card to
add or delete cards holder gives the
minimized in convenience of numeric
PIN codes password.
and extra computer literacy.

IP67 Rating stands against extremely
h e a v y w e a t h e r c o n d i t i o n w h i l e
keypad-free configuration always
leads no vandalistic.

O p t i o n a l i m p l e m e n t ,

simulator runs to rise satisfactory of
c a r d s h o l d e r m a n a g e m e n t
facilitation.

T S - 9 8 0

The Easiprox Split system is a low cost stand-alone

programmable access control system based on the EM400x
proximity tags and cards. The system consists of two units: a
controller (981-10) and a separate reader (982-10). The
memory and relay circuitry are located on the controller board
which can be installed in a secure location up to 50m away.

The reader is rated IP67 and can be installed in an outdoors

location. The system can store the codes of 2000 unique tags.
Adding and deleting tags is done by simple use of a Master
Tag. The optional Tag Simulator / Programming Unit allows
the programming (adding & deleting) of lost tags. The Relay
can operate in Pulse or Toggle mode.

Easiprox Split Stand Alone Reader

22.5

982-10

(Reader)

981-10

(Controller)

GIANNI INDUSTRIES, INC.

Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-Easiprox-Split Ver. D Published on 2010.03.24

Operating Voltage: 10~14 VDC or 8~12 VAC
Current Draw: Pull in: 110mA/12VDC
Holding :70mA/12VDC
RF Frequency: EM 125KHz
Input: 1 contact for request-to-exit button
Relays Electric Current: MAX . 3A/24VDC
Memory Volume: 2000 Proximity cards or tokens
Proximity Range: 10 cm (Depending on local installation
Conditions)
Relock Strike Time: 0.7~42 seconds
Visual Signals:
Yellow: Power on
Green: Add Tags
Red: Delete Tags
Yellow/Red: Clear Memory
Yellow (flash): strike mode and timer adjust
Operating Temperature: -20ºC~70ºC
Ambient Humidity: 5~95% relative humidity non-condensing
Case Material: ABS (UL94V0)
Color: Black

Specifications
