Gianni Industries GL-1800S - Manual

Statement
Specification
GIANNI INDUSTRIES, INC.
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-GL-1800S Ver. C Published on 2011.03.21
The product is warranted against defects in material and
workmanship while used in normal service for a period of 5
years from the date of sale to the original customer. The GEM
policy is one of continual development and improvement;
therefore GEM reserves the right to change specifications
without notice.
Warranty
GL-1800S is designed for surface mount on
outswing doors. With stainless steel housing, it is
suit
able for outdoor applications and severe
weather conditions. 1800 lb holding force meets
the needs for high security.
GL-1800S
WaterProof Electromagnetic Lock
Regular Installation
High reliability
Dual voltage 12 or 24 VDC (selectable)
MOV provides spike and surge protection
Anti-Residual magnetism function
Holding force up to 1800lbs
Features
Operating voltage: 12/24 VDC
Current draw: 500mA/12VDC; 250mA/24VDC
(at temperature 20ºC)
Operating temperature: -10~55ºC(14~131ºF)
Humidity: 0~95% non-condensing.
Holding force: Up to 1800 lbs(818 Kg)
Dimensions:
Magnet:(L) 284, (W) 71, (D) 46 mm
Armature plate:(L) 185, (W) 38, (D) 12 mm
Mounting plate:(L) 250, (W) 70, (D) 16 mm
Special finishes for magnet and armature plate: Zinc plated
Epoxy potting compound : E87252 (S), UL94V-0
Net Weight: 8.0 Kg
This series of Waterproof Magnetic Lock is epoxy
potting compound. Also, GEM Waterproof Series Magnetic
Locks have been proved to withstand water with the test
procedures of IPX7, IPX8 by a trusted third party. Therefore
users need not worry that the lock will rust or spark, if the lock
is in outdoor applications and installed in confined space
where inflammable gases are stored.
protected by
Magnet Armature
(Power Off)
Magnet Armature
(Power On)
Anti-residual statement
Our electromagnet locks feature Anti-Residual Magnetism
(ARM) which ensures the door can be opened without any
resistance from left over magnetism imparted to the armature
plate
No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: [email protected]
Website: gianni.tw
