Gianni Industries GEM L-150 User Manual

L-em150 bracket out-swing narrow frame doors

background image

L-EM150 Bracket
Out-swing narrow frame doors

Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-L-EM150 Ver. D Published on 2011.09.08

Application for the Electromagnet:
EM-150

20

0

41

Unit:mm

"L" brackets

L-150, L-EM150...

L-300,L-10001ST...

L-750, L-350,L-400...

L-500,L-600...

38mm

42mm

48mm

60mm

300 LBS

Magnet Grade

Optional Brackets

600 LBS

800LBS

1200 LBS

1

4

2

5

3

6

16mm

8mm

Hollow Metal Door

6.8mm for M8-1.25 thread

Reinforced Door

12.7mm

8mm

Solid Door

36mm

Power

Power

Finish

GIANNI INDUSTRIES, INC.

The A value in the table below shows the
minimum requirement distance of the door frame
for different electromagnetic lock model.

A Value

Installation of L bracket on Out-swing Doors

A s s e m b l e t h e
e l e c t r o m a g n e t a n d L
b r a c k e t w i t h a n A l l e n
wrench.

Turn on the power of
electromagnet. Let the
electromagnet and the
a r m a t u r e p l a t e b o n d
together. Press L bracket
against the door frame.

Fasten L bracket on the
door frame.

Test the unit. Tap the
p l u g s i n t o t h e
electromagnet

Drill a hole 8 mm in
diameter through the
d o o r. E n l a r g e t h e
hole to 16 mm from
outside.

Drill a hole 6.8 mm in
d i a m e t e r f r o m
inside. Screw with a
M8-1.25 thread.

F o l d t h e m o u n t i n g
template 90° angle along
the dotted line.

Drill a hole 8 mm in
diameter through the
d o o r. E n l a r g e t h e
hole to 12.7 mm from
o u t s i d e . T h e
thickness of the door
is 36 mm.

Drill the holes marked on
the template.

Magnet

A

rm

a

tu

re

Door Frame

Door
Leaf

A

Out-swing

No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: [email protected]
Website: gianni.tw
