Gianni Industries LZ-NH500N - Manual

LZ-NH500N Bracket
In-swing doors
GIANNI INDUSTRIES, INC.
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-LZ-NH500N Ver. C Published on 2011.09.08
Application for the Electromagnet:
EM-NH500 Series
2 1
6 7 Finish
4
5
3
Power
Unit:mm
19
0
63
.5
8
63
.5
6
63
.5
63
.5
19
0
48
26
7
75
With LZ bracket for in-swing doors
Use the fixing bolt to tighten
the electromagnet lock on the
L bracket Find a mounting location on the
door frame for the L bracket. Make
sure that the door is still closeable.
Close the door and connect the
power. Test the tightness and adjust
the Z bracket to fit the door. Lock tighten the Z bracket
Insert the guide pins into the
armature plate.
Assemble the armature plate and
the Z bracket. ( Must add rubber
washer)
Assemble the Z bracket, and make
sure that the Z bracket is adjustable.
M
in
im
a
l:
7
5
m
m
L-Bracket
Z-Bracket
In-swing
Frame
Door
Armature
Plate
