Gianni Industries LHS-50LH - Manual

Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-LHS Ver. C Published on 2008.05.16
The product is warranted against defects in material and
workmanship while used in normal service for a period of 1
year from the date of sale to the original customer. The GEM
policy is one of continual development and improvement;
therefore GEM reserves the right to change specifications
without notice.
Warranty
Statement
Dimension
Application
LHS-500 switched Lever Handle built in switch
output (N/C N/O contacts) for access controller
connections. Solid constructed unit brings door
egress convenience.
Unit: mm
51
.5 20
12
7.5
12
5
1.Green(Com.)
2.Red(N.C.)
3.Bla ck(N. O.)
1.Green(Com.)
2.Red(N.C.)
3.Bla ck(N. O.)
Swit ch
Before installation make sure door is "Left Hand" or "Right
Hand".
LHS-50LH (Left hand)
Left hand
Right hand
LHS-50RH (Right hand)
LHS-50
Switched Lever Handle
