Model G0694 (Mfg. Since 10/09)
The information contained herein is deemed accurate as of 5/7/2013 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2 Model G0694
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G0694 20" X 43" HEAVY-DUTY VARIABLE SPEED
WOOD LATHE
Product Dimensions:
Weight.............................................................................................................................................................. 578 lbs.
Width (side-to-side) x Depth (front-to-back) x Height................................................................... 103 x 25 x 49-1/2 in.
Footprint (Length x Width)..................................................................................................................... 77 x 16-1/2 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 854 lbs.
Length x Width x Height....................................................................................................................... 26 x 84 x 56 in.
Must Ship Upright................................................................................................................................................... N/A
Electrical:
Power Requirement........................................................................................................... 220V, Single-Phase, 60 Hz
Prewired Voltage.................................................................................................................................................. 220V
Full-Load Current Rating.......................................................................................................................................... 9A
Minimum Circuit Size.............................................................................................................................................. 15A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length................................................................................................................................................. 6 ft.
Power Cord Gauge......................................................................................................................................... 14 AWG
Plug Included........................................................................................................................................................... No
Recommended Plug Type..................................................................................................................................... 6-15
Switch Type.................................................................................................................... Push Button ON/OFF Switch
Inverter Type............................................................................................................................................ Delta VFD-E
Inverter Size......................................................................................................................................................... 3 HP
Motors:
Main
Type........................................................................................................................................... TEFC Induction
Horsepower................................................................................................................................................ 3 HP
Phase.................................................................................................................................................... 3-Phase
Amps.............................................................................................................................................................. 9A
Speed........................................................................................................................................... 50-1725 RPM
Bearings........................................................................................................ Sealed & Permanently Lubricated
Main Specifications:
Operation Information
Swing Over Bed......................................................................................................................................... 20 in.
Dist Between Centers................................................................................................................................ 43 in.
Swing Over Gap.................................................................................................................................. 24-7/8 in.
Swing Over Tool Rest................................................................................................................................ 16 in.
Swing Over Tool Rest Base................................................................................................................ 16-1/4 in.
No of Spindle Speeds............................................................................................................................ Variable
Spindle Speed Range................................................................................................................ 50 – 3000 RPM
Floor to Center Height............................................................................................................................... 45 in.
