Model G0694 (Mfg. Since 10/09)
-53-
Stand Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
2 P0694002 LEFT STAND (CABINET) 93 PFH69M FLAT HD CAP SCR M8-1.25 X 20
5 PLW05M LOCK WASHER 12MM 94 PCAP100M CAP SCREW M8-1.25 X 15
6 PLW05M LOCK WASHER 12MM 95 PCAP31M CAP SCREW M8-1.25 X 25
8 PB90 HEX BOLT 7/16-14 X 1-1/4 96 PLW04 LOCK WASHER 3/8
9 P0694009 L-BRACKET 97 PW02 FLAT WASHER 3/8
10 PLW01 LOCK WASHER 5/16 98 P0694098 INVERTER PWR CORD 2W 14AWG
11 P0694011 DOOR 104 P0694104 KEY 8 X 7 X 90
12 P0694012 STAND ACCESS HANDLE 106 P0694106 OUTBOARD MOUNTING BRACKET
13 P0694013 RUBBER FOOT 107 P0694107 OUTBOARD ARBOR SHAFT
14 PB32 HEX BOLT 5/16-18 X 5/8 108 P0694108 LOWER BRACKET
15 P0694015 PARTITION BOARD 109V2 P0694109V2 UPPER BRACKET V2.10.09
17 P0694017 RIGHT STAND 110 P0694110 ARBOR SHAFT TUBE
22 P0694022 MOTOR 111 P0694111 OUTBOARD LONG SHAFT
23 P0694023 MOTOR PULLEY 112 P0694112 OUTBOARD SHORT SHAFT
24 PSS20M SET SCREW M8-1.25 X 8 114 P0694114 ADJUST HANDLE M12-1.5 X 60
25 PSS19M SET SCREW M8-1.25 X 30 115 P0694115 ADJUST HANDLE M12-1.75 X 20
50 PCAP41 CAP SCREW 10-24 X 1/2 116 P0694116 ADJUST HANDLE M12-1.75 X 25
58 P0694058 TOOL REST 117 PB26M HEX BOLT M8-1.25 X 30
60 P0694060 L-BRACKET 118 PW01M FLAT WASHER 8MM
64 P0694064 LIMIT SWITCH CORD 2W 18AWG 119 PLN04M LOCK NUT M8-1.25
77 PN02 HEX NUT 5/16-18 120 PSS16M SET SCREW M8-1.25 X 10
80 PW07 FLAT WASHER 5/16 125 P0694125 LT STRAIN RELIEF PG11
83 P0694083 RESISTOR EACIN 300W 100 OHMS 126 P0694126 LT STRAIN RELIEF PG13.5
84 P0694084 INVERTER DELTA VFD-E 022E21A 129 P0694129 RUBBER HANDLE COVER
85 PS08 PHLP HD SCR 10-24 X 3/4 131 P0694131 LMT SWITCH SHINOZAKI AZD-1004
86 PN07 HEX NUT 10-24 132 P0694132 LIMIT SWITCH BRACKET
87 P0694087 POWER CORD 3 WIRE 14AWG 133 PS25M PHLP HD SCR M4-.7 X 35
88 P0694088 MOTOR CORD 4 WIRE 14AWG 134 P0694134 TERMINAL 3-POST (W/COVER)
90 P0694090 MOTOR BRACKET 135 PS03 PHLP HD SCR 10-24 X 1
91 P0694091 MOTOR MOUNT PLATE 136 PW03 FLAT WASHER #10
92 P0694092 BELT TENSION HANDLE 137 PLW03 LOCK WASHER #10
