Gianni Industries LZ-300 User Manual
Lz-300 bracket in-swing doors, Gianni industries, inc, With lz bracket for in-swing doors 2

M
in
im
a
l:
4
8
m
m
L-Bracket
Z-Bracket
In-swing
Frame
Door
Armature
LZ-300 Bracket
In-swing doors
GIANNI INDUSTRIES, INC.
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-LZ-300 Ver. E Published on 2011.09.08
26
25
0
42
25
0
48
5
30
Unit:mm
With LZ bracket for in-swing doors
2
Use the fixing bolt to tighten
the electromagnet lock on the
L bracket
1
Find a mounting location on the
door frame for the L bracket. Make
sure that the door is still closeable.
6
Close the door and connect the
power.
7
Test the tightness and adjust
the Z bracket to fit the door.
Finish
Lock tighten the Z bracket
4
Insert the guide pins into the
armature plate.
5
Assemble the armature plate and
the Z bracket. ( Must add rubber
washer)
3
Assemble the Z bracket, and make
sure that the Z bracket is adjustable.
Power
25
0
25
0
55
60
50
15
5
63
Application of the Electromagnet:
10001 ,10005(double), EM-300 Series
No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: [email protected]
Website: gianni.tw
