Control panel – Grizzly VS MILLING MACHINE G0669X User Manual
Page 55
g0669X precision 10" x 54" Vs Milling Machine
-53-
READ ELECTRICAL SAFETY
ON PAGE 49!
spindle Motor
on Button
spindle Motor
oFF Button
spindle
speed
dial
spindle
direction
switch
spindle
speed
readout
Coolant
pump
switch
Vertical power Feed
down Button
Vertical power Feed
Up Button
emergency stop
Button
Control Panel
figure 70. Control panel wiring.
