SECtION 5: ACCESSORIES
aCCessories
H6089—2 Axis Digital Read Out
(12" x 30")
H6093—3 Axis Digital Read Out
(12" x 30" x 5")
H7850—3 Axis Digital Read Out
(12" x 30" x 16 3 ⁄
4
")
you will be amazed the list of features for these
dros that include: selectable resolution down to
5µm, absolute/incremental coordinate display, arc
function, line of holes function, angled cuts func-
tion, 199 user defined datum points, centering/
cutter offset, double sealed scales, inches/mil-
limeters, calculator with trig functions, and linear
error compensation.
figure 44. 3 axis digital read out.
G1076—52-PC. Clamping Kit
this clamping kit includes 24 studs, 6 step block
pairs, 6 t-nuts, 6 flange nuts, 4 coupling nuts, and
6 end hold-downs. the rack is slotted so it can be
mounted close to the machine for easy access.
Made for
5 ⁄
8
" t-slots.
figure 45. g1076 52-pC. Clamping Kit.
H8368—Electric Power Drawbar
reduce your tool changing time to a fraction. this
easy-to-use power drawbar kit will enable you
to make tool changes in a flash on both manual
and CnC milling machines. it has enough torque
for tapers ranging from r-8 to nt50 and simple
installation is supported by complete instructions.
specifications: Motor 220V, 7.5 maximum amper-
age draw, 2100 rpM, and 240 ft/lbs.
figure 47. h8368 electric power drawbar.
H8257—Primrose Armor Plate with Moly-D
Machine and Way Oil 1-Quart
•
prevents stick slip and chatter due to superior
anti-friction capabilities resulting in greater
precision.
• provides the thinnest oil film possible while
effectively providing needed lubrication.
• superior rust and corrosion protection.
• adhesive/cohesive additive components for
vertical surfaces.
• resists squeeze out, running, dripping, and
is non-gumming.
figure 46. h8257 primrose armor plate with
Moly-d.
