CHAPTER 4: Upgrading Your Computer
64
4 Remove the screw that secures the front I/O panel
board to the computer, then remove the I/O panel
board by pushing it toward the back of the computer.
5 Disconnect the cable from the old I/O panel board and
connect it to the new I/O panel board.
6 Insert the new I/O panel board into the computer, then
replace the screw.
7 Place the front I/O assembly onto the computer, then
replace the screw.
8 Replace the front bezel by following the instructions in
“Replacing the front bezel” on page 44 .
9 Replace the side panel by following the instructions in
“Replacing the side panel” on page 44 .
Screw
