32

Replacing and Adding Drives

5

Remove the filler panel on the front bezel by squeezing the two tabs on
the left side of the filler panel. The filler panel then ejects.

6

Place the new diskette drive into the drive cage. Make sure the threaded
holes on the diskette drive align with the locking tab holes on the drive
cage.

7

Replace the drive locking tab.

8

Connect the power and data cables to the drive.

9

Push the release button in and slide the drive cage back into the chassis
until the button snaps into the rear locking hole.

10

Replace the right panel.

11

Reconnect the power cord and all other cords you removed, then turn
on the system.

Filler

panel

Drive cage
