Gianni Industries LZ-150 - Manual

LZ-150 Bracket
In-swing doors
GIANNI INDUSTRIES, INC.
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-LZ-150 Ver. E Published on 2011.09.08
Application for the Electromagnet:10003S
Unit:mm
With LZ bracket for in-swing doors
2 1
6 7 Finish
4
5
3
Power
32
17
0
24
5
37
17
0
28
18
0
38
6
40
6
48
30
18
0
Use the fixing bolt to tighten
the electromagnet lock on the
L bracket Find a mounting location on the
door frame for the L bracket. Make
sure that the door is still closeable.
Close the door and connect the
power. Test the tightness and adjust
the Z bracket to fit the door. Lock tighten the Z bracket
Insert the guide pins into the
armature plate.
Assemble the armature plate and
the Z bracket. ( Must add rubber
washer)
Assemble the Z bracket, and make
sure that the Z bracket is adjustable.
M
in
im
a
l:
3
7
m
m
L-Bracket
Z-Bracket
In-swing
Frame
Door
Armature
