g9249 12" x 37" Belt drive gap Bed lathe
Apron Parts List
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
301
P9249301
COLLAR 25MM
334
PSB30M
CAP SCREW M6-1 X 45
302
PK126M
KEY 5 X 5 X 32
335
P9249335
WORM GEAR
303
P9249303
WORM GEAR
336
P9249336
GEAR SHAFT 16 X 116T
304
PSB06M
CAP SCREW M6-1 X 25
337
PK48M
KEY 4 X 4 X 20
305
P9249305
BRACKET
338
PRP05M
ROLL PIN 5 X 30
306
P9249306
SLIDE BAR
339
P9249339
SHAFT
307
PSB68M
CAP SCREW M6-1 X 8
340
P9249340
SPUR GEAR
308
PS74M
PHLP HD SCR M4-.7 X 14
341
PRP49M
ROLL PIN 5 X 25
309
P9249309
COMPRESSION SPRING .8 X 5 X 1.5
342
P9249342
TRANSMISSION GEAR
310
P9249310
BRACKET
343
PRP38M
ROLL PIN 5 X 60
311
PSB01M
CAP SCREW M6-1 X 16
344
P9249344
HANDWHEEL GEAR
313
PSB24M
CAP SCREW M5-.8 X 16
345
P9249345
APRON CASTING
314
P9249314
GUIDE PLATE
346
P9249346
HANDWHEEL SEAT
315
PSS04M
SET SCREW M6-1 X 12
347
P9249347
GRADUATED COLLAR
316
P9249316
HALF NUT M25
348
P9249348
HANDWHEEL
317
P9249317
HALF NUT BRACKET
349
P9249349
HANDLE M8-1.25 X 63
318
P9249318
SPECIAL PIN
350
P9249002
BALL OILER
319
P9249279
STEEL BALL 6MM
351
P9249351
CLUTCH GEAR
320
PSS20M
SET SCREW M8-1.25 X 8
352
PR06M
EXT RETAINING RING 16MM
321
P9249321
COMPRESSION SPRING .8 X 10 X 1.5
353
P9249353
CLUTCH GEAR
322
P9249322
HALF NUT ROD
354
PRP08M
ROLL PIN 6 X 30
323
PRP28M
ROLL PIN 5 X 40
355
P9249355
CLUTCH GEAR
324
P9249324
HANDLE HUB
356
P9249356
SHIFTING BRACKET
325
P9249325
LEVER M12-1.75 X 50
357
P9249357
CHANGE ROD
326
P9249326
HANDLE
358
P9249358
CHANGE LEVER
327
P9249327
THREAD DIAL
359
PK29M
KEY 4 X 4 X 8
328
PRP61M
ROLL PIN 3 X 12
360
P9249360
CHANGE SHAFT
329
P9249329
INDICATOR GEAR
361
P9249361
CHANGE LEVER SEAT
330
PW03M
FLAT WASHER 6MM
362
P9249362
COMPRESSION SPRING 1 X 5 X 1.5
331
PSB26M
CAP SCREW M6-1 X 12
363
PSS74M
SET SCREW M8-1.25 X 35
332
P9249332
RIVET 2.5 X 5
364
PN03M
HEX NUT M8-1.25
333
P9249333
THREAD DIAL HOUSING
