-4-
g9249 12" x 37" Belt drive gap Bed lathe
The information contained herein is deemed accurate as of 5/29/2008 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 3 Model G9249
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G9249 12" X 37" BELT DRIVE GAP BED LATHE
Product Dimensions:
Weight............................................................................................................................................................ 1136 lbs.
Length/Width/Height............................................................................................................................. 64 x 27 x 49 in.
Foot Print (Length/Width)............................................................................................................................. 57 x 14 in.
Shipping Dimensions:
Carton #1
Type................................................................................................................................................. Wood Crate
Content..................................................................................................................................................Machine
Weight.................................................................................................................................................. 1024 lbs.
Length/Width/Height................................................................................................................... 71 x 29 x 29 in.
Carton #2
Type................................................................................................................................................... Cardboard
Content............................................................................................................................................... Left Stand
Weight...................................................................................................................................................... 76 lbs.
Length/Width/Height................................................................................................................... 27 x 18 x 14 in.
Carton #3
Type................................................................................................................................................... Cardboard
Content.............................................................................................................................................Right Stand
Weight...................................................................................................................................................... 58 lbs.
Length/Width/Height................................................................................................................... 27 x 15 x 11 in.
Electrical:
Switch........................................................................................... Magnetic Switch with Thermal Overload Protection
Switch Voltage...................................................................................................................................................... 220V
Recommended Breaker Size............................................................................................................................ 10 amp
Plug.......................................................................................................................................................................... No
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower.................................................................................................................................................2 HP
Voltage........................................................................................................................................................220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................Single
Amps............................................................................................................................................................7.5A
Speed.................................................................................................................................................1725 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ................................................................................................................................... Belt Drive
Bearings.................................................................................................. Shielded and Permanently Lubricated
