-72-
g9249 12" x 37" Belt drive gap Bed lathe
feed Rate Gearbox Parts List
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
201
PSB26M
CAP SCREW M6-1 X 12
244
PR03M
EXT RETAINING RING 12MM
202
PW03M
FLAT WASHER 6MM
245
P6201
BALL BEARING 6201
203
P9249203
GEAR
246
P9249246
SHAFT
204
PK19M
KEY 5 X 5 X 14
247
PSS74M
SET SCREW M8-1.25 x 35
205
P9249205
SHAFT
248
PN03M
HEX NUT M8-1.25
206
PSB04M
CAP SCREW M6-1 X 10
249
P9249249
BRACKET
207
P9249207
BEARING COVER
250
PSS02M
SET SCREW M6-1 X 6
208
P6003
BALL BEARING 6003ZZ
251
P9249251
BUSHING
209
PRP24M
ROLL PIN 5 X 16
252
P9249252
GEAR 16T
210
P9249210
DUPLEX GEAR
253
PK19M
KEY 5 X 5 X 14
211
P9249211
DUPLEX GEAR 16/32T
254
P9249254
GEAR SHAFT 16 X 34T
212
P9249212
BUSHING
255
P9249255
GEAR 36T
213
P9249213
GEARBOX CASTING
256
P9249256
SHAFT
214
P9249214
STRAIN RELIEF
257
P9249257
COMPRESSION SPRING 6 X 15
215
P9249215
OIL GASKET
258
P9249258
THREADED SHAFT
216
P9249216
CONTROL BASE
259
P9249259
HANDLE
217
P9249217
PLUG BASE
260
PN01M
HEX NUT M6-1
218
P9249218
PLUG
261
P9249261
OIL PIPE
222
P9249222
BUSHING
262
P9249262
OIL PIPE
223
PSS11M
SET SCREW M6-1 X 16
263
PRP03M
ROLL PIN 5 X 20
224
P9249224
LOCK COLLAR 20-2.5 X 30
264
PSB31M
CAP SCREW M8-1.25 X 25
225
PK144M
KEY 6 X 6 X 16
265
P9249265
SHIFTING FORK
226
P9249226
GEAR 24T
266
P9249266
GEAR 24T
227
P51104
THRUST BEARING 51104
267
P9249267
CONNECTING ROD
228
P9249228
BUSHING
268
P9249268
BUSHING
229
P9249229
SHAFT
269
P6201
BALL BEARING 6201
230
P9249230
GEAR 24T
270
P9249270
SHAFT
231
PK142M
KEY 6 X 6 X 32
271
P9249271
FRONT COVER
232
P9249232
GEAR 28T
272
P9249272
GEARBOX FRONT COVER
233
P9249233
GEAR 26T
273
PSB01M
CAP SCREW M6-1 X 16
234
P9249234
GEAR 24T
274
PRP26M
ROLL PIN 5 X 26
235
P9249235
GEAR 22T
275
P9249275
SHAFT
236
P9249236
GEAR 20T
276
P9249276
LEVER M10-1.5 X 50
237
P9249237
GEAR 19T
277
P9249277
HANDLE
238
P9249238
GEAR 18T
278
PRP28M
ROLL PIN 5 X 40
239
P9249239
GEAR 16T
279
P9249279
STEEL BALL 6MM
240
PK120M
KEY 5 X 5 X 75
280
P9249280
COMPRESSION SPRING 1 X 4.5 X 16-2
241
P9249241
BUSHING
281
P9249281
HANDLE HUB
242
P9249242
GEAR 16T
282
P9249282
SHAFT
243
P9249243
SHAFT
