GIANNI INDUSTRIES, INC.

Copyright 2008 Gianni industries, inc. All rights reserved.
DM-CA-DG-250 Ver. D Published on 2008.05.06

The products are manufactured under an ISO
9 0 0 1

Q C

0 8 0 0 0 0

C e r t i f i e d

Q u a l i t y

Management Program environment back its
product quality, performance and commitment
to customer satisfaction.

&

Features

Statement

The product is warranted against defects in material and
workmanship while used in normal service for a period of 1
year from the date of sale to the original customer. The GEM
policy is one of continual development and improvement;
therefore GEM reserves the right to change specifications
without notice.

Warranty

Specifications

Unit: mm

DG-250
Digital Keyless Entry System

38

82

11

6

2

1

3

4

5

6

7

8

9

0

#

*

Allows up to 49+50 PIN codes
Dual relays output for multi-control
Door Reed Switch Input for Anti-Trailing
Fully Programmable via keypad and master code
3 LED display with audible indication
Non-Volatile Memory
Invalid PIN Lock-out
Metal casting housing
With vandal resistant screws

Operating Voltage: 12~24 Vdc
Current Draw: Average 15mA, Peak 60mA @ 12Vdc
Input: request-to-exit, time out reed switch contact
Output: Dual relays, N.O./N.C./Com. Output (free voltage
contact)
Relays

: 2A MAX @30Vdc ,0.4A @ 120Vac

Relay Activation Time:*100,*200

Strike Time: 1~99 seconds
Strike mode: Access Timer or Latch

Memory Volume: 49+50 PIN codes

Relay 1 is controlled by 001~049 user slots
Relay 2 is controlled by 050~099 user slots

PIN codes: 5 digit codes only
Operating Temperature: -20~+70C
Ambient Humidity: 5~95% relative humidity non-
condensing
Factory Master Code: 12345
Invalid PIN Lock-out: The system will shut down for 60
seconds while 32 codes of incorrectly Master Codes
enrolled or PIN codes attempted(None beeper signal of
keypad activations)
EPROM:Non-volatile memory, System will retain all
programs and codes after a total loss of power.
Color: Beige White

Rating

The DG-250 is a dual relay digital code-operated for access

control keypad with up to 49+50 individual user PINs, user
access PINs ensure that all functions controlled to authorized
persons only. The door reed switch Input is used to time out
the timer when door is moved for Anti-Trailing. It's designed to
mount on a standard-single-gang electric wall box or on the
surface of an interior or exterior wall.

Logical memory can prevents unauthorized persons from

gaining PIN code entry by trial and error, The system will shut
down for 60 seconds while 32 codes of incorrectly Master
Codes enrolled or PIN codes attempted

None beeper signal

of keypad activations

.Metal die casting housing with vandal

resistant screws to seize every security measures of the unit;
an elegant contour dedicated with fashion coating which leads
DG-250 for matching up-to-dated door stile for compensable
application to the worldwide trend. The DG-250 is highly
reliable, warranted for life and capable of providing the best
read range in its class.

No. 13, Zhong Sing Road, Tu-Cheng Industrial Zone,
Tu-Cheng City, Taipei, Taiwan 23678
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: [email protected]
Website: gianni.tw
