Gianni Industries EM-10001LZ - Manual

EM-10001LZ Bracket
Inswing doors
GIANNI INDUSTRIES, INC.
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-EM-10001LZ Ver. E Published on 2011.09.08
Unit:mm
2 1
6 7 Finish
4
5
3
48
55
42
25
0
26
25
0
42
25
0
48
5
30
Power
Installation of LZ bracket on Inswing Doors
Install L bracket on the door frame.
M a k e s u r e t h e d o o r m a y b e
opened/closed. Fasten the electromagnet to L
bracket with fixing screws. Assemble Z bracket. Make sure it is
still loose. I n s e r t t h e g u i d e p i n s i n t o t h e
armature plate.
Fasten the armature plate to Z
bracket. Insert the rubber washer
between them. Close the door and turn on the
power. L e t t h e a r m a t u r e p l a t e a n d
electromagnet bond together. Press
Z bracket to the door leaf. Fasten Z bracket to the door leaf.
Application for the Electromagnet:
10001 , EM-300 Series
M
in
im
a
l:
4
8
m
m
L-Bracket
Z-Bracket
In-swing
Frame
Door
Armature
Plate
