Gianni Industries GS-200 - Manual (Page 2)

SMB-200
S
M
B
-2
0
0
S
M
B
-2
0
0
S
M
B
-2
0
0
35
48
18
2
Unit: mm
Optional Brackets
The unit may also be fitted semi-surface or surface
installation with the use of the SMB-200,UBK-182 and SMB-
250 Brackets. The magnet should be fitted to the door transom
and the housing holding armature on to the door. It is vital that
a minimum gap of 2mm exists between the magnet and the
armature, to allow correct operation.
GS200 Mini Shear Lock
UBK-182
U
B
K
-1
8
2
U
B
K
-1
8
2
Unit: mm
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-GS-200 Ver. G Published on 2011.09.14
14
48
18
2
GS200VGL
GS200VGL consists of GS200 shear lock, SMB-200 and UBK-
182 housings. Suitable for full frameless glass door and wall
10~13mm glass thickness.
Magnet
Assembly
Magnet
Assembly
Armature
Assembly
Armature
Assembly
Metal
Frame
Metal
Frame
Metal
Door
Metal
Jamb
Gla ss
Door
Surface Mount
Out
Out
In
In
In
Double action
metal door
Double action
glass door
In-swing metal door
2
m
m
Installation on Frameless Glass Door
Frameless
Glass Door
Frameless
Glass wall
GIANNI INDUSTRIES, INC.
Surface Mount
No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: [email protected]
Website: gianni.tw
