Notice – Grizzly Variable Speed Wood G0632 User Manual
Page 6

-4-
Model G0632 (Mfg. 4/12+)
Figure 2. Model G0632 headstock.
Motor
Motor Wiring
Junction Box
Spindle
Handwheel
Frequency Inverter
Spindle Lock
Front Belt Access
Panel
Control Panel
Motor Tensioning
Handle
Motor Mount Cap
Screw
Safety Cover
Headstock
Rotation Lock
Indexing Pin
Hole
NOTICE
The frequency inverter controls on the rear
of the headstock have no effect on the oper-
ation of the lathe. Opening the frequency
inverter will void the lathe warranty and
could seriously damage the lathe. DO NOT
open the case of the frequency inverter.
Figure 3. Model G0632 control panel identification.
Front Belt Access Panel
Spindle RPM Readout
Emergency STOP Button
Variable
Speed Dial
Spindle
Direction
Switch
