Model G0632 (Mfg. Since 1/09+)
READ ELECTRICAL SAFETY
ON PAGE 42!
Wiring Diagram Overview
Hot
Hot
Ground
6-15 Plug
(As Recommended)
G
Bl
Wt
Gn
Ground
U2
V2
W2
W1
V1
U1 Bk
Bk
Bk
Motor 220V, 3-Phase
Variable Speed
Control
Control Panel
(as viewed from the back)
REV/FWD
Switch
RPM Readout
& Circuit Board
RPM Sensor
Emergency
Stop
Wt
Wt
Wt
Wt Bl
View this page in color at
www.grizzly.com.
220V, 1-Phase
Br
Bl
Gn
Wt
Bk
Frequency
Inverter
Gn
Yl
Wt Rd
Bl
Bk
Br
Br
Rd
Bl
Wt
Bk
(Figure 58, Page 43)
(Figure 60, Page 43)
(Figure 59, Page 43)
(Wiring Page 45)
(Figure 59, Page 43)
Wiring Diagram
