Model G0632 (Mfg. 4/12+)
-47-
Stand Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0632001 SUPPORTING LEG 16 P0632016 TAILSTOCK LOCK HANDLE
2 P0632002 BED 17 PR07M EXT RETAINING RING 18MM
3 P0632003 BUSHING 19 P0632019 QUILL LOCK LEVER
4V2 P0632004V2 TOOL REST BASE LOCK BRACKET V2.02.08 20 P0632020 TAILSTOCK
5 PR11M EXT RETAINING RING 25MM 20-1 P0632020-1 COMPLETE TAILSTOCK ASSY
6 PR07M EXT RETAINING RING 18MM 21 PSS04M SET SCREW M6-1 X 12
7 P0632007 TOOL REST BASE 22 P0632022 HANDWHEEL
8 P0632008 TOOL REST 23 PCAP64M CAP SCREW M10-1.5 X 25
9 P0632009 TOOL REST LOCK LEVER 24 PLW06M LOCK WASHER 10MM
10 P0632010 TOOL REST BASE LOCK HANDLE 25 P0632025 CLAMP
11 P0632011 LIVE CENTER 26 PN29M HEX NUT M18-2.5
12 P0632012 QUILL 27 PN02M HEX NUT M10-1.5
13 P0632013 TAILSTOCK LOCK BRACKET 28 P0632028 MACHINE FOOT
14 P0632014 BUSHING 29 P0632029 HANDWHEEL HANDLE
15 P0632015 LEADSCREW
