Model G0632 (Mfg. 4/12+)
-49-
Headstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
30 P0632030 COMPLETE HEADSTOCK ASSY 61-8 P0632061-8 FRONT MOTOR BEARING
31 P0632031 SPUR CENTER 61-9 P0632061-9 REAR MOTOR BEARING
32 PSS11M SET SCREW M6-1 X 16 62 PSS11M SET SCREW M6-1 X 16
33 P0632033 FACEPLATE 63 PK33M KEY 5 X 5 X 45
34 P0632034 SPINDLE 64 P0632064 MOTOR PULLEY
35 PK12M KEY 5 X 5 X 30 65 PSS11M SET SCREW M6-1 X 16
36 P6207-2RS BALL BEARING 6207 2RS 66 PCAP64M CAP SCREW M10-1.5 X 25
37 P6206ZZ BALL BEARING 6206ZZ 67 PCAP64M CAP SCREW M10-1.5 X 25
38 PR38M INT RETAINING RING 62MM 68 PW04M FLAT WASHER 10MM
39 PR15M EXT RETAINING RING 30MM 69 P0632069 MOTOR MOUNTING PLATE
40 P0632040 INDEX PIN 70 P0632070 FEMALE KNOB M8-1.25
41 P0632041 HEADSTOCK 71 PN29M HEX NUT M18-2.5
42 P0632042 HEADSTOCK WIRING HARNESS 72 P0632072 CLAMP
43 PR07M EXT RETAINING RING 18MM 73 P0632073 HEADSTOCK LOCK BRACKET
44AV2 P0632044AV2 HEADSTOCK LOCK HANDLE ASSY V2.01.09 74 P0632074 BUSHING
44V2 P0632044V2 STRAIGHT LOCK HANDLE ROD V2.01.09 75 PR17M EXT RETAINING RING 26MM
44V2-1 P0632044V2-1 THREADED HANDLE V2.01.09 76 P0632076 ROTATION BRACKET
44V2-2 P0632044V2-2 KNOB 2PC V2.01.09 77 P0632077 ROTATION LOCK PIN
45 P0632045 BRAKING RESISTOR 78 P0632078 COMPRESSION SPRING
46 PHTEK12M TAP SCREW M5 X 15 79 P0632079 SPINDLE LOCK PIN
47 PCAP33M CAP SCREW M5-.8 X 12 80 P0632080 PLATE
48 P0632048 FREQUENCY INVERTER 81 P0632081 BRACKET
48-1 P0632048-1 FREQ INV SAFETY COVER 82 PCAP10M CAP SCREW M5-.8 X 15
49 P0632049 WIRING BRACKET 83 PS08M PHLP HD SCR M5-.8 X 12
50 P0632050 POWER CORD 84 P0632084 FRONT BELT ACCESS PANEL
51 P0632051 MOTOR WIRING HARNESS 85 P0632085 VARIABLE SPEED KNOB
52 PS55M PHLP HD SCR M3-.5 X 10 86 P0632086 VARIABLE SPEED CONTROL
53 P0632053 STRAIN RELIEF 87 P0632087 FWD/REV SWITCH
54 P0632054 RIBBED BELT 180J6 88 P0632088 EMERGENCY STOP SWITCH
55 PSS80M SET SCREW M8-1.25 X 15 90 P0632090 FLAT HD SCR M3-.5 X 30
56 P0632056 SPINDLE PULLEY 91 P0632091 RPM READOUT CIRCUIT BOARD
57 PS08M PHLP HD SCREW M5-0.8 X 12 92 P0632092 RPM READOUT LED
58 P0632058 SIDE BELT ACCESS PANEL 93 P0632093 RPM SENSOR
59 P0632059 SPINDLE HANDLE 94 PN07M HEX NUT M3-.5
59-1 P0632059-1 HEX BOLT M8-1.25 X 140 95 PS50M PHLP HD SCR M3-.5 X 12
59-2 PN03M HEX NUT M8-1.25 96 P0632096 FLAT HD SCR M3-.5 X 20
59-3 P0632059-3 RUBBER WASHER 8MM 97 P0632097 CONTROL PLATE
59-4 P0632059-4 SPINDLE HANDLE SAFETY COVER 98 PR07M EXT RETAINING RING 18MM
60 P0632060 KNOCKOUT TOOL 101 P0632101 STUD-FT M3-.5 X 25
61 P0632061 MOTOR 1-1/2HP 220V 3PH 102 PN07M HEX NUT M3-.5
61-1 PS49M PHLP HD SCR M3-.5 X 5 103 PS09M PHLP HD SCR M5-.8 X 10
61-2 PLW09M LOCK WASHER 3MM 104 P0632104 DIVIDING PLATE
61-3 PW07M FLAT WASHER 3MM 105 P0632105 COMPRESSION SPRING
61-4 P0632061-4 FAN COVER 106 P0632106 ROTATION LOCK PIN NUT
61-5 P0632061-5 FAN 107 P0632107 COMPRESSION SPRING
61-6 P0632061-6 MOTOR JUNCTION BOX 108 PR39M EXT RETAINING RING 8MM
61-7 P0632061-7 JUNCTION BLOCK 109 PSS31M SET SCREW M5-.8 X 8
