Model G0632 (Mfg. Since 1/09+)
-43-
READ ELECTRICAL SAFETY
ON PAGE 42!
Electrical Components
Figure 58. Model G0632 control panel wiring
(shown from the back of the panel).
Figure 60. Model G0632 RPM sensor wiring.
Figure 59. Model G0632 motor junction box
wiring.
RPM Readout
& Circuit Board
Emergency
Stop Button
Variable
Speed
Control
REV/FWD
Switch
Electrical Components
Figure 61. Model G0632 frequency inverter
wiring.
RPM Sensor
