The product is warranted against defects in material and
workmanship while used in normal service for a period of 1
year from the date of sale to the original customer. The GEM
policy is one of continual development and improvement;
therefore GEM reserves the right to change specifications
without notice.
Gianni supplies all accessories for access control application
including maglock, electric bolt lock, electric strike ,exit button,
power supply, prox cards or fobs.
Keyprox Plus
Access Control System
RS-485 must be used where the distance between the controller
and the PC is greater than 30 meters or for installation of
multiple controllers. The PC will require a 311 converter to
interface between RS-232 and RS-485. The drawing below
shows a typical connection of multiple controllers with a 311-30
converter.
Multi-Controller System
Warranty
AC IN N L - + 12VDC 0.5A
P.B. NO NC COM
Door strike 1
3 core
2 core
2
c
o
re
2
c
o
re
3 core
2 core
Controller
Address 15
Reader 15 A
Alarm or trigger output
Exit 1
Button
Door Sw 1
Reader 15 B
AC IN N L - + 12VDC 0.5A
P.B. NO NC COM
Door strike 1
3 core
2 core
2
c
o
re
2
c
o
re
3 core
2 core
Controller
Address 0
311: RS-232/485
interface
Reader 0A
Power supply
Power supply
Alarm or trigger output
Exit 1
Button
Door Sw 1
Reader 0B
Total Cable Length Max. 1000 meters
Maximum of 16 Controllers
