EB260 electric dropbolt incorporates a mechanical cylinder
to lock or unlock the door manually in case of an unexpected
power failure.
EB260/EB260M
ELECTRIC DROPBOLT
Dimensions
Specification
Fail-Secure Version (Power to Unlock)
Operating Voltage: 12~28 VDC
Voltage Tolerance: ±10%
Current Draw: Pull in: 1.0A, Holding: 0.3A/12VDC
(at 20°C)
Operating Temperature: -10~+45°C
Humidity: 0~95% non-condensing.
Tested over 500000 cycles.
Faceplate Material: Zinc alloy
Auto-relocking Time Delay : 1.5, 3 ,6 ,9 seconds
Net Weight: 1.3 Kg
Locked and unlocked status output (EB260M)
45 5 mm maxi
Reed
The door close sensor can detect within a range of 5 mm.
If the door gap is too wide, a magnet within the strike plate can
be adjusted to improve detection accuracy.
Adjustable Sensor
GIANNI INDUSTRIES, INC.
Door locking time delay lasts from 1.5 to 9 seconds
adjustable by jumper PINs.
1.5 seconds 3seconds 6 seconds 9 seconds
Relock Time Delay
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-EB-260 Ver. F Published on 2011.06.22
Unit: mm
48
30
2
6
0
2
2
0
38
260
240
3
0
220
1
6
20 20
3
5
27
3
