Finalizing the Installation
(for qualified installers only)
© Travis Industries
4090102
100-01212_000
Log Installation
NOTE: The logs are a mirror-image (same logs fit on left and right side). Both the 36 CF See
Through (ST) and Pier use the same log set. See the pictures below for log placement
Bottom 3 logs.
Middle 2 logs.
