Page 29
Installation
(for qualified installers only)
29
© Travis Industries
4090102
100-01212_000
Approved Vent Configuration – Top Vent, Vert. Term. (1 45
°
,2 90
°
Elbows)
•
The termination must fall within the shaded area shown in the chart. Use the indicated restrictor
positions.
5 feet
0 feet
0 feet
5 feet
0 feet
20 feet
20 feet
5 feet
10 feet
5 feet
10 feet
0 feet
15 feet
20' (max)
10 feet
15 feet
15 feet
20' (max)
10 feet
15 feet
25 feet
40 feet
(max.)
40 feet
(max.)
25 feet
30 feet
35 feet
30 feet
35 feet
Exhaust Restrictor # 3
Exhaust Restrictor # 2
Figure 19
