10 Installation
(for qualified installers only)
© Travis Industries 4090102 100-01212_000
Fireplace Placement Requirements
•
Fireplace must be placed in a room with a minimum 96” ceiling.
•
Fireplace must be placed directly on the sub-floor or wood platform (not on linoleum or carpet).
•
Fireplace must be installed on a level surface capable of supporting the fireplace and vent.
•
This heater may be placed in a bedroom. Please be aware of the large amount of heat this
appliance produces when determining a location.
Clearances
•
When installed, walls that protrude to the sides of the fireplace must be a minimum 12” from the
glass frame (tile stop).
•
Due to the high temperature, the heater should be located out of traffic and away from furniture
and draperies.
•
Fireplace must be placed so the vents below and above the glass do not become blocked.
Raised Fireplaces
•
The fireplace (and hearth, if desired) may be placed on a platform designed to support the
fireplace and vent.
Platform
Minimum 78” Fireplace
Enclosure Height.
Optional Raised Hearth
(see “Hearth Requirements” for details)
Figure 4
