Freescale Semiconductor i.MX27 PDK 1.0 Hardware User's Guide, Rev. 1.0 5-11
Signal Pin Description
FEC_COL F39 FEC interface (NC for i.MX27)
FEC_TX_ER F40 FEC interface (NC for i.MX27)
FEC_ENABLE F41 FEC interface (NC for i.MX27)
FEC_TX_EN F42 FEC interface (NC for i.MX27)
VDD_FEC_IO F43 FEC interface (NC for i.MX27)
EB0 F46 LSB Byte strobe WEIM data enable;
Controls d[7:0]
1_WIRE_DATA F47 1 Wire data
LBA F48 WEIM load base address
USB_OTG_UID F49 USB OTG ID signal
AUDIO_LOUT_R G1 Audio Line out right
HEADPHONE_RIGHT G2 Headphone right
HEADPHONE_RETURN G3 Headphone return(Connect with GND)
SPEAKER_RIGHT_P G4 Handset loudspeaker and alert amplifier
positive terminal
SPEAKER_RIGHT_N G5 Handset loudspeaker and alert amplifier
minus terminal
CMOS_FM_RST G12 Camera sensor and FM module reset signal
CSI_PWDN G13 Camera sensor power down
KP_ROW_7 G14 Keypad row 7
KP_ROW_6 G15 Keypad row 6
KP_ROW_5 G16 Keypad row 5
KP_ROW_4 G17 Keypad row 4
KP_ROW_3 G18 Keypad row 3
KP_ROW_2 G19 Keypad row 2
KP_ROW_1 G20 Keypad row 1
KP_ROW_0 G21 Keypad row 0
KP_COL_7 G22 Keypad column 7
KP_COL_6 G23 Keypad column 6
KP_COL_5 G24 Keypad column 5
KP_COL_4 G25 Keypad column 4
KP_COL_3 G26 Keypad column 3
KP_COL_2 G27 Keypad column 2
KP_COL_1 G28 Keypad column 1
KP_COL_0 G29 Keypad column 0
GPS_INT_B G30 GPS Interrupt
