i.MX27 PDK 1.0 Hardware User's Guide, Rev. 1.0 Freescale Semiconductor 5-10
Signal Pin Description
HDD_D13 E39 HDD Data 13
HDD_D14 E40 HDD Data 14
HDD_D15 E42 HDD Data 15
VDD_HDD_IO E43 HDD IO Power supply
USB_OTG_D_PLUS E50 USB OTG data plus
AUDIO_LIN_L F1 Audio Line in left
BOOTSTRAP_0 F4 Boot Strap 0
BOOTSTRAP_1 F5 Boot Strap 1
BOOTSTRAP_2 F6 Boot Strap 2
BOOTSTRAP_3 F7 Boot Strap 3
BOOTSTRAP_4 F8 Boot Strap 4
BOOTSTRAP_5 F9 Boot Strap 5(Not used for i.MX27)
VDD_BOOTSTRAP F10 Boot Strap Power supply
USB-HS-D4 F15 USB Host Data 4
USB-HS-D5 F16 USB Host Data 5
USB-HS-D6 F17 USB Host Data 6
USB-HS-D7 F18 USB Host Data 7
USB-HS_NXT F19 USB Host ULPI Next signal
USB-HS_DIR F20 USB Host ULPI Direction signal
FEC_TXD2 F22 FEC interface (NC for i.MX27)
FEC_TXD3 F23 FEC interface (NC for i.MX27)
FEC_RX_ER F24 FEC interface (NC for i.MX27)
FEC_TXD0 F25 FEC interface (NC for i.MX27)
FEC_RXD1 F26 FEC interface (NC for i.MX27)
FEC_RXD2 F27 FEC interface (NC for i.MX27)
FEC_RXD3 F28 FEC interface (NC for i.MX27)
FEC_TXD1 F29 FEC interface (NC for i.MX27)
FEC_MDIO F30 FEC interface (NC for i.MX27)
FEC_MDC F31 FEC interface (NC for i.MX27)
FEC_CRS F32 FEC interface (NC for i.MX27)
FEC_INT_B F33 FEC interface (NC for i.MX27)
FEC_TX_CLK F34 FEC interface (NC for i.MX27)
FEC_RXD0 F35 FEC interface (NC for i.MX27)
FEC_RX_DV F36 FEC interface (NC for i.MX27)
FEC_RESET_B F37 FEC interface (NC for i.MX27)
FEC_RX_CLK F38 FEC interface (NC for i.MX27)
