Model LR16 [Recorder function / Other functions]
Assigning the destinations of SUB IN and the
memory play signals
You can assign the destination channels of
the signal received from the [SUB IN] jacks on
the control panel as well as the memory play
signal.
(3) Use the [MENU] dial to highlight
"Sys default memory" and press the
[ENTER] key.
The confirmation screen as below is shown.
(4) While holding down the [RECORD] key,
press the [ENTER] key.
System initialization is performed
immediately and the display returns to the
Home screen previously shown before
entering MENU mode.
(1) Press the [ENTER] key to bring up the
MENU screen.
When you bring up the MENU screen for
the first time, "Mark point" is highlighted.
(2) Use the [MENU] dial to highlight "Input" and
press the [ENTER] key.
The display now shows the screen on which
you can assign the destination channels of
"SubIn" and "MemPlay".
(3) While the "Assign/SubIn" item is
highlighted, press the [ENTER] key.
The current setting ("15/16" by default)
starts flashing.
: To cancel system initialization,
press the [STOP] key.
The display now shows the system menu
screen.
• To assign the destination channels of SUB IN
(4) Use the [MENU] dial to select the
destination channels and press the
[ENTER] key.
You can select from channel pairs ("1/2",
"3/4" and "5/6") as well as "-/-".
When "-/-" is selected, no channel is
assigned.
