Appendix A
( SRS -1050 Installation
Page A-9
Multiple Unit Installations
Bridging at the NT1
The overall maximum length of
cable is 1600 ft. The TR switch
on the Terminal Equipment
farthest from the NT1 should be
ON. The TR switches on all
other Terminal Equipment
should be OFF. The TR
switches on the NT1 should be
set to ON at 100 Ohms. NT1
timing switches (if present)
should be set to ADAPTIVE (or
PTP).
NT1 (TR = ON 100 Ohms)
Terminal Equipment (TR = OFF)
Terminal Equipment (TR = OFF)
Terminal Equipment (TR = ON)
Notes
