4.4.101. Map Descriptor Example 97 - edit read analog address
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Ana_Addr, Rd_Triggers, 13, art, SYSPLUS_01, Ed_Rd_Ana_Addr, Ed_Rd_Ana_Addr, 0, 1
This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows:
Offset from Store_Data_Array_Offset Description
0
Analog address
4.4.102. Map Descriptor Example 98 - edit read units
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Units, Rd_Triggers, 14, art, SYSPLUS_01, Ed_Rd_Units, Ed_Rd_Units, 0, 1
This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows:
Offset from Store_Data_Array_Offset Description
0
Units value
4.4.103. Map Descriptor Example 99 - edit read fuzzy heat cycle time
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Fuz_Hct, Rd_Triggers, 15, art, SYSPLUS_01, Ed_Rd_Fuz_Hct, Ed_Rd_Fuz_Hct, 0, 1
This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows:
Offset from Store_Data_Array_Offset Description
0
Heat cycle time
