4.4.8. Map Descriptor Example 5 - read setpoint channel
// Client Side Map Descriptors
Map Descriptors
Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Address, Length
Setpoints_00, 0s, Setpoints, 0, rdbc, SYSPLUS_01, Setpoint, 0, 1
The channel is specified by the “Address” field.
4.4.9. Map Descriptor Example 6 - set setpoint channel = value
// Client Side Map Descriptors
Map Descriptors
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Address, Length
Setpoints_00, Setpoints_0, 0, awt, SYSPLUS_01, Setpoint, 0, 1
The channel is specified by the “Address” field. value is retrieved from the value written into Data_Array_Name at
Data_Array_Offset.
4.4.10. Map Descriptor Example 7 - read pv channel
// Client Side Map Descriptors
Map Descriptors
Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Address, Length
Pvs_00, 0s, Pvs, 0, rdbc, SYSPLUS_01, Pv, 0, 1
The channel is specified by the “Address” field.
4.4.11. Map Descriptor Example 8 - read deviation channel
// Client Side Map Descriptors
Map Descriptors
Map_Descriptor_Name, Scan_Interval, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Data_Type, Address, Length
Deviation_00, 0s, Deviations, 0, rdbc, SYSPLUS_01, Deviation, 0, 1
The channel is specified by the “Address” field.
