4.4.88. Map Descriptor Example 84 - edit read program
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Program, Rd_Triggers, 0, art, SYSPLUS_01, Ed_Rd_Program, Ed_Rd_Program, 0, 1
This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows:
Offset from Store_Data_Array_Offset Description
0
Program number
4.4.89. Map Descriptor Example 85 - edit read step
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Step, Rd_Triggers, 1, art, SYSPLUS_01, Ed_Rd_Step, Ed_Rd_Step, 0, 1
This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows:
Offset from Store_Data_Array_Offset Description
0
Step number
4.4.90. Map Descriptor Example 86 - edit read number steps
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Store_Data_Array_Name, Store_Data_Array_Offset, Length
Ed_Rd_Num_Steps, Rd_Triggers, 2, art, SYSPLUS_01, Ed_Rd_Num_Steps, Ed_Rd_Num_Steps, 0, 1
This command is triggered by writing any value to Data_Array_Name at Data_Array_Offset.
The retrieved data is stored as follows:
Offset from Store_Data_Array_Offset Description
0
Number of steps
