FS-8700-88 Envirotronics SystemsPlus Page 25 of 49
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]
4.4.55. Map Descriptor Example 52 - edit clear program
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length
Ed_Clr_Program, Ed_Clr_Program, 0, wrbx, SYSPLUS_01, Ed_Clr_Program, 1
Any value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.
4.4.56. Map Descriptor Example 53 - use emulator mode
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length
Use_Emu_Mode, Misc_Cmds, 0, wrbx, SYSPLUS_01, Use_Emu_Mode, 1
A value of 1 to use emulator mode or a value of 0 to return to command mode must be written to Data_Array_Name at
Data_Array_Offset to trigger this command. Note that all driver RDBC function Map Descriptors are stopped when entering emulator
mode. Map Descriptors will resume polling when returning to command mode.
4.4.57. Map Descriptor Example 54 - end edit mode
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length
End_Edit_Mode, Misc_Cmds, 1, wrbx, SYSPLUS_01, End_Edit_Mode, 1
Any value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.
4.4.58. Map Descriptor Example 55 - edit set cycles = num_cycles
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length
Ed_Set_Cycles, Ed_Cycles, 0, wrbx, SYSPLUS_01, Ed_Set_Cycles, 1
A value of num_cycles must be written to Data_Array_Name at Data_Array_Offset to trigger this command.
