4.4.43. Map Descriptor Example 40 - edit alarms
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length
Edit_Alarms, Edit_Alarms, 0, wrbx, SYSPLUS_01, Ed_Alarms, 1
Triggger this command by writing any value to Data_Array_Name at Data_Array_Offset.
4.4.44. Map Descriptor Example 41 - set circulators = Boolean
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length
Set_Circs, ManualControl, 0, wrbx, SYSPLUS_01, Set_Circs, 1
Write a value of 1 for “on” or 0 for “off” to Data_Array_Name at Data_Array_Offset to trigger this command.
4.4.45. Map Descriptor Example 42 - set lights = Boolean
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length
Set_Lights, ManualControl, 1, wrbx, SYSPLUS_01, Set_Lights, 1
Write a value of 1 for “on” or 0 for “off” to Data_Array_Name at Data_Array_Offset to trigger this command.
4.4.46. Map Descriptor Example 43 - select program program_num
// Client Side Mao Descriptors
Map Descriptor
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, SysPlus_Cmd, Length
Select_Program, Program_Num, 0, wrbx, SYSPLUS_01, Select_Prog, 1
A program_num value must be written to Data_Array_Name at Data_Array_Offset to trigger this command.
