FUJITSU IMAGE FI-5530C2 User Manual
Page 86
70
2. Click the [Multifeed] button.
⇒ The following dialog box appears.
3. Configure settings in the [Specify Area for Multifeed Detection] dialog box.
1) Mark the [Enable] check box.
2) Select whether you want to specify an area to enable or disable multifeed detection.
• To specify an area for which the Multifeed Detection is performed:
⇒ Select the [Select area for applying Multifeed Detection] button.
• To specify an area for which the Multifeed Detection is NOT performed:
⇒ Select the [Select area for not applying Multifeed Detection] radio button.
3) Specify the [Start] position in the area.
Enter a distance from the top of the document as a starting position in millimeter.
(Select an even number from 0 mm to 510 mm)
4) Specify the [End] position in the area.
Enter a distance from the the top of the document. (Select an even number from 0 mm
to 510 mm)
HINT
•
You can specify an area in the direction of the length of the document
for detecting multifeed errors.
•
Unless the [Enable] checkbox is marked, the area of [Select area for
applying Multifeed Detection] or [Select area for not applying Multifeed
Detection] cannot be specified. In this case, normal multifeed detection
described above is performed. (Refer to
ATTENTION
The number you enter as the [End] position must be larger than that of
the [Start] position.
