5.3 Remedying Common Troubles
fi-5530C2 Image Scanner Operator’s Guide
123
TR
OUBLESHOO
T
ING
5
*1) For details on the requirements, refer to "6.2 Document Quality" on page 133.
*2) For details on multifeeds, refer to "6.5 Specifying How to Detect Multifeed" on page
139.
*3) For details on how to set paper thickness switch, refer to "2.3 Scanning Thin
Documents" on page 48.
*4) For details on how to clean the rollers, refer to "3.2 Cleaning the ADF" on page 90.
*5) For details on how to clean the Ultrasonic sensor, refer to the "3.2 Cleaning the ADF"
on page 90.
*6) For details on how to replace (or attach) the Pad ASSY, refer to "4.2 Replacing the Pad
ASSY" on page 99.
*7) For details on how to clean the Pad ASSY, refer to "3.2 Cleaning the ADF" on page 90.
YES Clean the Pad ASSY.(*7) Is the Pad ASSY dirty?
Is the Pad ASSY worn out?
YES Replace the Pad ASSY.(*6)
NO
Is the Pad ASSY attached
correctly?
NO Attach the Pad ASSY
correctly.(*6)
YES
NO
Continued from the previous page
Is the document stack 10mm (A4)/
5mm (A3) or less?
NO Reduce the number of
sheets in the stack.
YES
If you cannot solve the problem
after taking measures, check the
items in "5.4 Items to check before
contacting the dealer where you
bought the scanner" and contact
the dealer or an authorized
FUJITSU service provider.
