62
2.6 Excluding a Color from Images (Dropout Color)
You can select a color from primary colors (red, green, and blue) to remove (drop out) from a
scanned document image. For example, when you scan a document containing black text with
green background, you can output an image of only black text.
Enable the dropout color setting in the setup dialog box of the scanner driver.
The following shows the procedure to change settings in the setup dialog box of FUJITSU TWAIN
32 Scanner Driver.
1. From ScandAll PRO, display the setup dialog box of FUJITSU TWAIN 32.
For information about how to display the setup dialog box of the scanner driver, refer to
section
"1.5 How to Use ScandAll PRO" on page 29 .
2. In the TWAIN Driver dialog box, click the [Advance] button.
⇒ The [Advance] dialog box appears.
ABC ABC
Original Created image
Example: When green is selected as a dropout color
