June 2004 © 2004 Foundry Networks, Inc. A - 1
Appendix A
Specifications
This appendix includes technical information about the operating environment, power application, interfaces,
cable pinouts, MIBs, and physical cables and adapters used to connect the Foundry AR1202 and AR1204 router
to a network.
System Specifications
The following tables provide various technical specifications for the Foundry AR1202 and AR1204 router.
Table A.1: Environment, Hardware, Memory, and Power
Environment
Operating temperature 32° F to 104° F (0° C to 40° C)
Storage temperature – 32° F to 158° F (0° C to 70° C)
Relative humidity 5 to 90%, non-condensing @ 104° F (40° C)
Altitude 0 to 13,123 ft. (0 to 4,018 meters)
Dimensions
Height 1.32 inches (3.35 cm)
Width 8.65 inches (21.97 cm)
Depth 6.61 inches (16.79 cm)
Weight 1.5 lbs (.675 kg)
Memory
Default 256 MB DRAM
Default 16 MB Flash
Storage for multiple configurations
AC Power
