Foundry AR-Series AR1202 and AR1204 Installation Guide
3 - 4 © 2004 Foundry Networks, Inc. June 2004
Wall-Mounting Option
An optional wall-mounting assembly is available for mounting the AR1202 and AR1204 router on a vertical surface. The
wall-mount components are shipped in the same box with the AR1202 and AR1204 router, and are shown in the following
figure:
Figure 3.6 Wall-Mount Components
Rack-Mounting Option
An optional rack-mounting tray is available for installing the AR1202 and AR1204 router in an equipment rack. The
following items are shipped in a separate carton:
Wall-mount bracket
Power supply strap Router to wall-mount bracket screws: (4) 4-40 x
.250 inch Phillips pan head
Hollow wall anchors Wall-mount screws: (4) 6 x 1 inch Phillips pan head
