Foundry AR-Series AR1202 and AR1204 Installation Guide
4 - 6 © 2004 Foundry Networks, Inc. June 2004
Configuring Drop and Insert Multiplexing
To use this feature, WAN ports 1 and 2 must be active and licensed for use. Drop and insert supports one-to-one
mapping of 1 to 24 voice-carrying DS0s on the PBX interface to the equivalent DS0s on the network port. The
PBX is connected to WAN port 1 and the DS0s are mapped to the carrier facility on WAN port 2.
In this example, DS0 channels 1-10 and 18-24 from WAN links 1 and 2 are configured for drop and insert traffic.
The remaining DS0 channels (11-17) are available for IP traffic.
Configure the drop_insert interface
The interface name can be a maximum of 8 characters.
Configure the mode type
The mode type can be one of the following three values:
0 data only (default)
1 data and voice
2 voice only
Table 4.4: E1 Interface Default Configuration
Parameter Default Value Optional Values
framing crc non-crc
disabled
linecode HDB3 no optional value
clock_source internal line
linemode short_haul long_haul
jitter enabled disabled
lbo 43 db 12 db
yellow_alarm generate and detect no optional value
Table 4.5: Terminal Emulation Defaults
Setting
9600 bps
8 data bits
1 stop bit
no parity
XON/XOFF flow control
host/configures interface drop_insert Foundry
