Product Introduction
June 2004
© 2004 Foundry Networks, Inc.
2 - 5
Table 2.4: AR1204 Back-Panel Ports
Connector
Description
WAN 1 - WAN 4
WAN connection port. These ports accept cables with RJ-48C connectors. If
drop and insert is configured, then ports 1 and 2 are reserved for that
feature.
FE 0 - FE 1
Ethernet LAN connection ports. These ports accept cables with RJ-45 cable
connectors.
AUX
Reverse telnet connection. This port accepts a cable with a male DB-9
connector.
Console
Console management port. This port accepts a cable with an RJ-45 cable
connector.
DC power
12 VDC power connection. This port accepts the 2 mm. power connector on
the DC power supply cable that ships with the AR1204 router.
