40 ServerView Remote Management Frontend
User interfaces Working with the Remote Management Frontend
Console area
The console area contains the display from the redirected console. In the
console area, you can also enter SAC commands if a Windows system with an
activated Emergency Management Services (EMS) is booted.
Console redirection bar
You use the Enter Console and Leave Console buttons in the console redirection
bar to start or terminate a console redirection session.
Status bar
The Remote Management Frontend status bar contains the following displays
and controls:
Logoff You click this button to terminate a connection to the
iRMC/ iRMC S2/BMC.
I
You can use the Logon and Logoff buttons to
terminate and re-establish the connection to the
managed server as often as you want without
having to leave the window.
Connected / Not
connected A left-aligned string indicates whether or not a
connection exists.
A right-aligned string indicates the status of the console
redirection:
– offline (on a red background)
– online (on a green background)
Table 5: RemoteView Frontend window - status bar
Table 4: Remote Management window - connection bar
