34 ServerView Remote Management Frontend
User interfaces Working with the Remote Management Frontend
4.1.1 Remote Management window for Remote Manager
and Console Menu
The following section describes the components of the Remote Management
window for the Remote Manager (iRMC/ iRMC S2, RSB/ RSB S2/ RSB S2 LP
(3HU)) and the Console Menu application (RemoteView Management Blade).
I
The structure of the Remote Management window is identical for the Telnet
and SSH-based Remote Manager and for the Console Menu application.
The only differences relate to the displayed port numbers: 3172 (Telnet
port) and 22 (SSH port, only for a connection to iRMC/ iRMC S2).
Figure 12: Remote Management window for Remote Manager and Console Menu application
Connection bar
Status bar
Console area
Online help
