ServerView Remote Management Frontend 37
Working with the Remote Management Frontend User interfaces
Status bar
The Remote Management Frontend status bar contains the following displays
and controls:
Connected to address>
A left-aligned string indicates the status of the
connection, the IP address and the port number of the
iRMC/ iRMC S2 or RSB/ RSB S2/ RSB S2 LP (3HU) or
the RemoteView Management Blade.
A right-aligned string indicates the status of the
connection:
– offline (on a red background)
– online (on a green background)
– online SSL (on a green background)
indicates an SSL Telnet connection
– online SSH (on a green background)
indicates an SSL connection
Table 3: RemoteView Frontend window (Remote Manager) - status bar
